Titanium Dioxide Rutile Sulphuric Acid Process Used In Architectural Coatings

Titanium Dioxide Rutile Sulphuric Acid Process Used In Architectural Coatings

    • Titanium Dioxide Rutile Sulphuric Acid Process Used In Architectural Coatings
    • Titanium Dioxide Rutile Sulphuric Acid Process Used In Architectural Coatings
    • Titanium Dioxide Rutile Sulphuric Acid Process Used In Architectural Coatings
    • Titanium Dioxide Rutile Sulphuric Acid Process Used In Architectural Coatings
  • Titanium Dioxide Rutile Sulphuric Acid Process Used In Architectural Coatings

    Product Details:

    Place of Origin: Shanghai, China
    Brand Name: Liangjiang
    Certification: ISO/REACH/SGS/ROSH
    Model Number: R258

    Payment & Shipping Terms:

    Minimum Order Quantity: 1MT
    Price: negotiation
    Packaging Details: Bag:Plastic and paper compound valve bag, net weight of each bag: 25kgs
    Delivery Time: Within 10 workdays after payment
    Payment Terms: 30% TT prepayment, 70% against the copy of BL,Irrevocable sight LC,West Union, D/A, D/P
    Contact Now
    Detailed Product Description
    Model Name: Rutile Titanium Dioxide R258 MF: TIO2
    Production Process: Sulphuric Acid Process ElNECS No.: 236-675-5
    Classification: Titanium Dioxide Surface Treatment: Widely Used In Architectural Coatings, Industrial Paint, Anti-corrosion Coatings, Paints, Powder Metallurgy, Masterbatch And Plastic Products, Etc.
    CAS No.: 13463-67-7 Grade Standard: Industrial Grade
    High Light:

    titanium dioxide rutile

    ,

    titanium dioxide pigment

     CAS No. 13463-67-7 rutile titanium dioxide tio2 manufacturers uses in paints

    Specifications:

    1,  rutile titanium dioxide pigment R258 is manufactured by the sulphate process and supplied as a fine, dry powder, which are inorganic coated with zirconium,Al2O3&SiO2 and special organic surface treated to have both good optical properties and excellent pigment properties. With advanced control technology of particle-size and particular coating technology, the products show good whiteness, high gloss, great hiding power, strong tinting power, favorable weatherability , high chalk resistance, low oil absorption, good wetting and are easy to disperse in a variety of systems.

    Applications:

    Widely used in architectural coatings, industrial paint, anti-corrosion coatings, paints, powder metallurgy, masterbatch and plastic products, etc.

    Basic data:

    Itemtitanium dioxide(TiO2)
    CAS NO.13463-67-7
    EINECS NO.236-675-5
    color indexing77891, white pigments
    ISO591-1:2000R2
    ASTM D476-84III, IV
    Appearancewhite powder
    true specific gravity4.1 g/cm3
    apparent density0.7~1.0 g/cm3
    surface treatmentCoated with Zr and Al + special organic treatments


    Typical technical index( Standard:Q/VAIP1-2010)

    PropertyR218
    TiO2 content %≥91.0
    Rutile content %≥98.0
    Color (compared with standard sample)
    ∆L*(sample-standard sample)
    ∆s=(∆a2+∆b2)0.5
    not lower than
    ≥-0.3
    ≤0.5
    Matter volatile at 105ºC %≤0.8
    Matter soluble in water %≤0.5
    Residue on sieve 45µm %≤0.1
    PH of aqueous suspension6.5-9.0
    Brightness %≥94.6
    Oil absorption g/100g≤21
    Tinting strength , Reynolds number≥1860


    packing specification:
    Adopted plastic woven bags or paper and plastic compound bags, net weight is 25%, or packaged as customer’s request in 500kgs or 1000kgs bags.

    Storage and transportation safety:
    Store in a cool, dry, well-ventilated area away from incompatible substances
    Wash thoroughly after handling. Remove contaminated clothing and wash before reuse. Use with adequate ventilation. Minimize dust generation and accumulation. Avoid contact with eyes, skin, and clothing. Avoid breathing dust.

    2.Titanium dioxide anatase, titanium dioxide antase coated, titanium dioxide rutile sulfuric process, titanium dioxide rutile chlorination process:

     Anatase TiO2Coated Anatase Tio2Sulfuric acid process rutile Tio2Chloride process rutile TiO2
    powderIndoor powderIndoor powderIndoor/outdoor powderIndoor/outdoor powder
    Usage amountlargelittlelargeless
    Dispersibilitybadgoodgoodgood
    Covering powerbadbadgoodbetter
    Surface propertiesbadgoodgoodGood
    liquiditybadgoodgoodgood
    Yellowing resistancebadbadgoodbetter
    Color stabilitybadnormalgoodbetter


    Applications:
    1. Characteristic requirements for titanium dioxide in coatings and paints

    ItemBuilding Coat
    Normal temperature drying enamel paint (Little porcelain paint type)emulsion coatings
    Outdoorweather resistance, Hiding power, aesthetic propertyweather resistance, Hiding power, aesthetic property( Little outdoor)
    IndoorHiding power, aesthetic propertyHiding power, aesthetic property
    itemIndustrial Coat
    automobilehome electrical appliances
    Finish coatweather resistance, Hiding power, aesthetic property , dispersibilityHiding power, aesthetic property
    floating coatweather resistance, Hiding power, dispersibility
    primer coatdispersibility

    Coatings industry consumes most qty of titanium dioxide, especially the rutile type. The global coating industries occupy 58% - 60%, mainly because the aspects of the performance is much better than the other white pigments. So the coating using by titanium dioxide is much higher than ordinary filler, because titanium dioxide is an integral part of in the coating, covering and adornment, its role is not only more important is to improve the physical and chemical properties of paint, bust also to improve the mechanical strength of the coating, adhesion, anticorrosive, light and weather resistance.So during of the production of coatings, It’s reasonable for us to choose the suitable type and specs!
