High Durable Pigment Titanium Dioxide Fiber Grade , Coating Tio2 CAS No. 13463-67-7

High Durable Pigment Titanium Dioxide Fiber Grade , Coating Tio2 CAS No. 13463-67-7

  • High Durable Pigment Titanium Dioxide Fiber Grade , Coating Tio2 CAS No. 13463-67-7
High Durable Pigment Titanium Dioxide Fiber Grade , Coating Tio2 CAS No. 13463-67-7
Product Details:
Place of Origin: China
Brand Name: LiangJiang
Certification: ISO/REACH/SGS/ROSH
Model Number: Urethane Elastic Fiber Grade
Payment & Shipping Terms:
Minimum Order Quantity: 1Ton/Tons
Price: negotiation
Packaging Details: Plastic and paper compound valve bag, net weight of each bag: 25kgs;1 Pallet can be packed 40 bags by PE film/ 1 ton/ 40bags;1x20' FCL can be loaded 20 Pallet/ 20 ton/800bags. 1x20' FCL can be loaded 22 ton/ 880bags without pallet.;If you have special req
Delivery Time: 10 working days after received your payment
Payment Terms: 30% T/T in advance, the balance against the copy of B/L;Irrevocable Sight L/C;western Union、D/A、D/P
Supply Ability: 3000Ton/Tons per Month
Contact Now
Detailed Product Description
Model Name: Chemical Fiber Grade Titanium Dioxide For Urethane Elastic Fiber Applications: Primarily Used As Matting Agent In Urethane Elastic Fiber Manufacturing.
Content: 98% Crystal Size: 2um
CAS No.: 13463-67-7 EINECS: 2366755
HS: 3206111000 Appearance: White Powder
Supply Ability: 3000Ton/Tons Per Month
High Light:

tio2 anatase

,

tio2 rutile

white pigment Chemical Fiber Grade Titanium Dioxide For Urethane Elastic Fiber

Specifications:

Liangjiang brand- Chemical Fiber Titanium Dioxide For Urethane Elastic Fiber , The high-quality product is produced by adopting the improved production method of LJ-A300 Chemical Fiber TiO2 in accordance with German technological process, and is primarily used as matting agent in urethane elastic fiber manufacturing.

Typical technical data sheet( standard: Q/VAIP-2010)


Item

Index

Analysis result

Appearance

White Powder

White Powder

purity(TiO2)%             ≥

93.0

94

Fe%                       ≤

0.010

0.005

Water  %                  ≤

1.0

0.36

PH

6.5-8.0

7.5

45μmresidue on sieve %    ≤

0.03

0.02

Loss on ignition % (m/m)    ≤

0.2

0.15

Grain size

0.2-0.3

0.22

Resistivity Ω/cm            ≥

7000

10000

Penetration amount

Normal

-

100%

Heat up

-

100%

Filter performance testing  ba

3.0-4.0

0.36

Interface sedimentation test

Non-delamination

Non-delamination

Non-sedimentation

Non-sedimentation

Bene-dispersion

Bene-dispersion

Hue

L(Brightness) ≥

96

98.57

a(Red hue)  ≤

0.3

-0.33

b(Yellow hue)≤

0.4

0.32



Packing: Conventional packing of chemical fiber titanium dioxide is 25kg net weight/bag or 1000kg per pallet.
Transportation: In transportation, chemical fiber titanium dioxide should be kept dry and free from exposure to rain. Combined shipment with goods that may deteriorate its quality or damage the packing is strictly prohibited. Ensure product safety and packing cleanliness during transportation.
Storage: In storage, chemical fiber titanium dioxide should be kept dry, ventilated and free from exposure to light, and is preferably kept indoors or in a place with a canopy. The storage site should be kept clean and free from exposure to sunlight, moisture and rain. The validity period is 3 years as of the date of production. Upon the expiration of the validity period, the product is subject to re-inspection of all items and approval before it is used.

Description:


Titanium dioxide fiber grade have the basic features of white pigment, the special request for particle size, particle distribution, whitness, impurity contents and so on.


Titanium dioxide, another important application fields, Textile and chemical fibre industry as flatting agent.Generally, using anatase in fibers because of the more softness than rutile. Titanium dioxide fiber grade doesn’t need surface treatment. But using in some special products, to bring down the tio2 photochemical action, avoid fiber in the role of tio2 photocatalysis drop solution.


1. The refractive index contrast between white pigment and synthetic fiber:



White pigment


refractive index

Synthetic fiber

refractive index

Tio2( anatase)

2.55

Polyester

1.725

Tio2(rutile)

2.76

polyacrylonitrile

1.515

Barium sulfate

1.64

Acetate

1.37

Zinc oxide

2.02

viscose

1.546

antimony oxide

2.19

Ketone ammonia

1.572

Zinc sulfide

2.37

Nylon-6

1.558

lithopone

1.84

Nylon-66

1.558

Tio2, high opacity, One of the most basic characteristics of good white pigments. Opacity is caused by refractive index difference between pigments and the surrounding mediums.
When refractive index of pigments and the refractive index of binder the same, shows transparent; When refractive index of pigments is greater than the refractive index of blinder, it is opaque, the larger difference, the stronger opacity.

The sheet shows the refractive index of pigments is higher than of general white pigments,two times as the refractive index of common synthetic fiber, besides, small particle size, good dispersibility, stable chemical properties, so putting 0.2% to 0.5% tio2 into the synthetic fiber can reach the flatting effects.

2. The cost of tio2 using in fiber is about 1%, the using of tio2 fiber grade is not like of the coatings. Using in coatings, if not good whiteness, matching color to remedy. If bad fitness, grinding repeatedly. If the bad quality of tio2 as Flatness, it will immediately cause the filter at a slower pace, and blockage of the jet hole, broken wires, hair silk, bad appearances of the fibers and so on. Liangjiang brand- titanium dixoide fiber grade, fine particles, almost no coarse particle, narrow particle size distribution and uniform, good dispersibility, and less impurity content, When using, not wear pipe, nozzle and wire cutting knife;Chemical stability, heat resistance, good resistance to light easy dispersion in bulk, fiber, and scattered and good stability, small filter resistance;After the extinction , not affects the strength of the fiber and spinning processing, once the sample passes the test, we can ensure the quality stability.





we aspires to be the supplier of  the world's leading chemical raw materials, show our value of the products made in China!
