Home ProductsChloride Process Titanium Dioxideengineering plastics grade Chloride Process Titanium Dioxide For PVC PE No.236-675-5

engineering plastics grade Chloride Process Titanium Dioxide For PVC PE No.236-675-5

    • engineering plastics grade Chloride Process Titanium Dioxide For PVC PE No.236-675-5
    • engineering plastics grade Chloride Process Titanium Dioxide For PVC PE No.236-675-5
    • engineering plastics grade Chloride Process Titanium Dioxide For PVC PE No.236-675-5
    • engineering plastics grade Chloride Process Titanium Dioxide For PVC PE No.236-675-5
  • engineering plastics grade Chloride Process Titanium Dioxide For PVC PE No.236-675-5

    Product Details:

    Place of Origin: Shanghai, China
    Brand Name: Liangjiang
    Certification: REACH/SGS/ISO/ROSH
    Model Number: R804

    Payment & Shipping Terms:

    Minimum Order Quantity: 1MT
    Price: negotiation
    Packaging Details: 25kg per plastic & paper compound bag
    Delivery Time: Within 10 workdays after payment
    Payment Terms: 30% TT prepayment, 70% against the copy of BL,Irrevocable sight LC,West Union, D/A, D/P
    Contact Now
    Detailed Product Description
    Model Name: Chloride Process Rutile Titanium Dioxide R804 Classification: Rutile Titanium Dioxide
    Appearance: White Powder Application: PVC (polyvinyl Chloride), PE(polyethylene), PPR(polypropylene), PS(polyethylene), Engineering Plastics。
    HS: 3206111000 CAS No.: 13463-67-7
    ElNECS No.: 236-675-5 Marks: Customization Available

    engineering plastics grade Chloride Process Titanium Dioxide For PVC PE No.236-675-5




    Specifications:


    1. Chlorination process titanium dioxide



     Liangjiang Brand rutile titanium dioxide R804 introduced foreign advanced chloride process technology

    for the manufacturing of Titanium Pigment,mainly manufacturing chloride process rutile titanium pigment

    (referred as R type), which is very important white pigment and ceramics glaze with excellent performance.



    It also has excellent whiteness, tinting strength, hiding strength, weather resistance, heat resistance ,

    chemical stability , especially no toxicity compared with other white pigments, and is widely

    used in the following industries: coatings , plastic, paper making, printing ink, chemical fiber,

    enamel, rubber, and cosmetics etc.



    Advantages: using the less impurities artificial rutile of 90% tio2 purity as the raw material, short process flow, production capacity easy to expand and continue, high quality.



    Disadvantages: because of the monopoly of the foreign companies, it’s hard to bring in the foreign technology and equipment in China. Besides, due to the raw material of high content titanium dioxide ore, the production cost is relatively high and the process is hard.



    Due to the different raw materials and production process, the product performance is different and has different requirements to the weather resistance, hiding power, aesthetics and dispersion titanium dioxide. So the clients should choose titanium dioxide of different quality based on their needs.



    Classification:

    Rutile titanium dioxide

    Model Name:

    Rutile titanium dioxide R804

    Production process:

    chloride process

    MF:

    Tio2

    Titanium Dioxide Certificate

    ISO/REACH/SGS/ROSH

    Grade Standard

    Industrial grade

    Supply Ability

    4,500 MT per month

    Appearance

    White powder

    Place of Origin:

    Shanghai China (Mainland)

    Port

    Shanghai

    Application:

     PVC (polyvinyl chloride), PE(polyethylene), PPR(polypropylene), PS(polyethylene), engineering plastics.

    Basic data:

    Chemical Name

    Titanium dioxide(TiO2)

    CAS No.

    13463-67-7

    EINECS No.

    236-675-5

    ISO591-1:2000

    R2

    ASTM D476-84

    III, IV

    Appearance

    White powder

    BET

    4.1 g/cm3

    Density

    0.7~1.0 g/cm3

    Surface treatment

    TiO2, Silicon, Aluminum coats and special organic treatment

    Factory

    Shanghai liangjiang titanium white products co.,ltd



    Typical technical index( Standard:Q/VAIP1-2010)



    Index

    R 804

    TiO2 %

    ≥92.5

    Surface treatment

    Al, TI, Si, Organic

    L*(acrylic paint system)%

    ≥98

    B *(acrylic paint system)%

    ≤0.35

    Whiteness(acrylic paint system)%%

    ≥97

    Hiding power(acrylic paint system)%

    ≥95

    Relative tinting strength

    (acrylic paint system, comparison with R902+)%

    ≥96

    Oil dispersibility H

    ≥6.0

    Oil absorption g/100g

    ≤19

    PH value of water suspensions

    6-8

    Resistivity of water suspensions (Ω.m)

    ≥75

    105℃ volatile%

    ≤0.5

    Redidue (45µm sieve)  %

    ≥0.1

    Whiteness (compared to sample)
    ∆L*( samples- standard samples)
    ∆s=(∆a2+∆b2)0.5

    Unlower
    ≥-0.3
    ≤0.5



     packing specification:



    Adopted plastic woven bags or paper and plastic compound bags, net weight is 25%,

    or packaged as customer’s request in 500kgs or 1000kgs bags.



    Storage and transportation safety:



    Store in a cool, dry, well-ventilated area away from incompatible substancesWash thoroughly after handling.

    Remove contaminated clothing and wash before reuse. Use with adequate ventilation.

    Minimize dust generation and accumulation. Avoid contact with eyes, skin, and clothing.

    Avoid breathing dust.



    2. Titanium dioxide compared with other kinds of white pigment :



    Name

    Relative Density

    Refractive index

    Tint reducing

    hiding power

    Reynolds number

    relative value

    Tiatnium dioxide rutile Chlorination process

    4.0

    2.85

    1800

    105

    105

    Tiatnium dioxide rutile sulfuric process

    4.2

    2.76

    1650

    100

    100

    Titanium dioxide anatase

    3.91

    2.55

    1270

    77

    78

    Barium sulfate

    4.5

    1.64







    zinc oxide

    5.6

    2.02

    200

    12

    14

    lithopone

    4.2

    1.84

    260

    16



    BasicLeadCarbonate

    6.1

    2

    150

    9

    12

    zinc sulfide

    4

    2.37

    660

    40

    39



    Applications:





    1. Titanium dioxide quality requirements for plastic, PVC and masterbatch



    Items

    Performance

    Hiding power

    Lighter and thinner plastic products can be produced using tio2 of good hidinding power

    Whiteness

    Decide the appearance of the white or light color palstic products

    light color or white color

    Dispersibility

    Affect the production cost of plastic products as bad dispersibility affects the  smoothness and brightness

    Weather resistance

    The outdoors plastic products and plastic doors and windows require the weather resistance of tio2

    Machinability

    Titanium dioxide machinability is the vital key to the production efficiency and cost in the production of white masterbatch (especially the concentration variety)

    Performace impact

    Titanium dioxide volume of addition can affects the quality of the plastic products, especially in the condition of larger addition



    Plastic is the second largest parts for titanium dioxide, occupying about 20% of the total world titanium dioxide demands, There are more than 50 brands belongs to plastic specials in the world 500 barands. Requirements for plastic, fine particle, good dispersion performance;Good heat resistance and light resistance,During the heat and the plastic forming process , the finished product does not change color in sunlight exposure and use process. Most of the particle size in plastic is fine. In the plastics, to join titanium dioxide can improve the heat resistance of plastic products, light fastness, weather resistance, make the plastic products to improve the physical and chemical performance.The strong mechanical strength can extend their life!



    The effect of titanium pigment in the plastics industry mainly has two aspects, one is used as the basic white pigment, provide cover (white color); the second is to block uv light, used as uv screen disadvantages agent, used for outdoor plastic products to provide a good weatherability. For the Common plastic,it does not require the weatherability, focuses

    More on the paint performance requirements.



    Due to the characteristics of palstic products, When choosing different, should be taken into account in accordance with the technical requirements of plastic products, mainly to choose anatase or rutile, not same as the coatings, inks, paints.



    2. Titanium dioxide quality requirements for paper production:



    classification

    Tio2  classification

    Notes

    rutile

    anatase

    decorative paper



    Higher Anti-aging requirement

    High ash paper





    Better Hiding power

    Low ash paper



    Better opacity

    coinage paper



    Better opacity



    Paper is the third largest parts for titanium dioxide, As the paper filter, mainly use in high grade paper and thin paper. To join titanium dioxide in the paper can make the paper good whiteness, good gloss, high strength, thin and smooth, not penetrate when printing, light quality.Titanium dioxide for Paper generally use the titanium dioxide without the surface treatment, can have the effect of fluorescent whitening agent, increase the whiteness of paper, but laminated paper use requires the surface treatment of rutile titanium, to meet the requirements of light resistance and heat resistance.



    Different paper use, different type titanium dioxide, titanium dioxide rutile, good oxidation resistance good weather resistance, mainly used for decorative paper and high ash paper of weather resistance; While titanium dioxide anatase used for the low transparency and low ash paper,not high rquirement for  weather resistance.Although chlorination process and sulfuric acid process can produce rutile type, but the chlorination process titanium pigment , whiteness, the red crystal type of content, especially the stability of the finished product is better than that of the sulfuric acid method, suitable for use in the decorative paper and high ash;And coinage in the paper and the low ash must be used titanium dioxide by sulfuric acid, in order to meet the requirements of opacity for two kinds of paper.

    engineering plastics grade Chloride Process Titanium Dioxide For PVC PE No.236-675-5
